Heavy Duty Plate Mount Casters 5" Polyurethane 1320 lbs, Pkg Qty 4

Overview

This heavy-duty caster set is engineered for rigorous industrial environments where superior load distribution and floor protection are paramount. The package includes a complete four-wheel configuration, comprising two swivel units for enhanced maneuverability and two rigid units for stable linear tracking. Designed to support substantial weights, the assembly delivers a combined load capacity of 1,320 lbs, making it ideal for moving heavy machinery, large transport carts, and industrial workstations. The wheels feature a high-grade polyurethane tread that offers an optimal balance between durability and floor safety, preventing scuffing or damage to concrete, epoxy, and tile surfaces while ensuring smooth rolling resistance even under maximum load conditions.

Key Features

Total system load capacity rated at 1,320 lbs Configuration includes two swivel and two rigid casters for controlled movement 5-inch polyurethane wheels provide excellent shock absorption Non-marking tread protects sensitive industrial flooring Robust plate mount design ensures secure equipment attachment Low rolling resistance reduces operator fatigue during manual pushing High-impact housing withstands demanding warehouse conditions

Specifications

Wheel Diameter: 4.9 in Load Capacity: 1,320 lbs Wheel Material: Polyurethane Mounting Type: Plate Mount Plate Dimensions: 4.3 x 3.7 in Package Quantity: 4 casters per set Configuration: 2 Swivel, 2 Rigid Application Environment: Indoor and protected outdoor industrial use

Applications

Heavy manufacturing equipment relocation Industrial material handling carts Large-scale assembly line workstations Warehouse logistics and storage racks Medical imaging and laboratory equipment bases Food processing machinery requiring frequent sanitation moves Automotive service lifts and tool cribs The plate mount interface measures 4.3 by 3.7 inches, providing a broad surface area for bolt-on installation that minimizes stress concentrations on the host equipment frame. This mounting style is preferred in applications where vibration resistance and structural integrity are critical. The polyurethane wheel composition is specifically selected for its ability to resist oils, greases, and common industrial solvents, extending the service life of the casters in harsh chemical environments. Unlike softer rubber compounds, this material maintains its shape under heavy static loads, preventing flat-spotting when equipment remains stationary for extended periods. The combination of swivel and rigid units allows operators to steer loads with precision while maintaining a straight path during long-distance transport, reducing the risk of accidental collisions in narrow aisles. This caster system represents a reliable solution for facilities requiring a blend of high weight capacity, floor friendliness, and operational stability without compromising on mobility.
